Single phase regulator

Product Overview
TDGC2, TDGC2\TSGC2, TSGC2J series contact regulator products are the 14th batch of energy-saving products for the electromechanical industry. This product has the characteristics of no distortion, small size, light weight, high efficiency, convenient use and reliable operation. Can be widely used in industry (such as chemical, metallurgy, instrumentation, electromechanical manufacturing, light industry, etc.), scientific experiments, public equipment, household appliances, to achieve voltage regulation, temperature control, speed regulation, dimming and power control purposes The contact auto-coupling regulator developed and researched by our company adopts advanced science and technology and meets national and industry standards.

Structural features
The contact type regulator adopts imported silicon steel sheet and is an energy-saving new product made by advanced processing technology. According to the required voltage, the single-phase contact regulator can be freely adjusted from 0~250V or 0~300V (special). The three-phase contact regulator can be freely adjusted from 0~430V or 0~520V (special). The regulator has the characteristics of high efficiency, small magnetic leakage, low loss, low temperature rise, low noise, low vibration, strong instantaneous overload capability, convenient use, reliability, and long-term operation.
The coil is the main component of the voltage regulator, it has the following properties:
1. It adopts high magnetic permeability oriented straight steel sheet, so the loss is small.
2. Adopt mechanical automatic winding, uniform between and , each line is straight and parallel, so the contact surface is flat.
3. Using a heat-resistant resin material to dip and solidify, making the regulator more resistant to heat.
4. Use mechanical grinding to make the contact surface smooth as a mirror.
5. The traditional multi-carbon brush design is adopted to increase the contact surface of the brush, reduce the current that each carbon brush receives, and reduce the temperature rise. 6. Use high-performance brushes to increase conductivity and eliminate fireworks.
7. Use copper surface soldering to reduce contact resistance and reduce temperature rise.
8. The use of heat-resistant elastic metal material, the mechanical pressure is stable for a long time, reducing the temperature rise of contact.

Technical Parameters

Input voltage Simplex 220
The output voltage Simplex 0-250
Working frequency 50Hz/60Hz
Effectiveness >90%
Waveform distortion No additional distortion
Temperature rise <60°C
Dielectric strength 2000V/min
Insulation resistance Simplex >5MΩ



Product main specifications

Phase Model Specification(KVA) Hhysical dimension L*W*H(mm) Weight(kg)
Simplex HK-TDGC₂J 0.5 140*160*200 4.2
1 170*210*230 6.5
2 210*250*230 11.8
3 240*270*230 14.5
5 350*380*270 26
7 350*380*270 26.5
10 350*430*430 54
15 350*430*590 80
20 350*430*590 83
30 350*430*1100 165
40 350*430*1100 171
Simplex HK-TDGC₂ 0.2 120*110*120 3
0.5 140*130*130 4
1 200*180*180 6.5
2 200*180*200 9
3 220*180*200 11
5 310*240*240 16
10 310*240*410 36
15 310*240*560 48
20 310*240*770 56
30 310*240*1500 105
